5T Electric Driven Transfer Platform For Robot Arm Handling

Product Brief

2 sets 5t mobile cable power electric driven transfer platforms were delivered to NanJing automatic workshop, the transfer platforms were used in production line for robot arm handling, the running distance is 8m. As per the working requirement, the transfer platform should realize automatically stop when reach required position by plc control system.

Working Principle

The electric driven transfer platform is powered by the tow cable directly introduces the 380V cable into the electric control system of the transfer platform to control the start, stop, forward and backward of the transfer platform. The cable placed on the ground is dragged by the movement of the flat car to realize the power supply of the transfer platform. The cable is placed in the center of the two tracks, and the operating system is controlled by a low-voltage 36V power supply.

Optional Configuration

1. The load capacity, table size and rail inner distance can be customized according to customer needs;

2.  Optional protection cable, cable suspension, etc.;

3. Optional automatic stop and limit limit device when encountering people;

4. Optional on-board operation, fixed point operation, radio remote control, etc.;

5. Optional frequency converter stepless speed regulation;

6. Optional explosion-proof, high temperature requirements;

7. Optional lifting, climbing, weighing, self-unloading and other systems;

Product Information:

Model: KPT

Power: Cable Powered

Capacity: 5 Ton

Table Size: 800*4500*300mm

Running Speed: 0-20m/min

Running Distance: 8m

Color: Yellow, operational color

Rail Type: P18

Operation Type: Hand Pendant + Remote Control

Warranty: 2 years

Advantage: Manufacturer of rail transfer cart; free provide design solution; free supply vulnerable part
