AGV Transfer Cart Automated Guided

Product Brief

The AGV transfer cart is a kind of fully steerable, self-propelled transport cart designed for industrial fields workshop material and workpiece transfer from one bay to another.

The automated guided AGV transfer cart equipped with an electromagnetic automatic navigation device, after finished the computer controlled programming. AGV can auto follow the specified magnetic nail route, with the rechargeable battery as its power source, Magnetic nail is fixed on the floor along the pre-set driving path. Two sensors are installed symmetrically at both ends of the AGV cart, and 16 sensors points are installed on the sensors. The degree of deviation from the path is calculated by the change of the sensor points. The automatic control system can manage the AGV steering through this deviation, and the continuous dynamic closed-loop control system can ensure the AGV automatically and accurately follow the pre-set path.

Product Information:

Model: AGV-2T

Load: 2 Tons

Size: 2500*1300*450mm

Wheel Type: Automated Guided Wheels

Power Supply: Battery Drive

Working Speed: 0-24mmin (variable speeds)

Customized Is Supported
