Product Information:

Model: KPD

Capacity: 65 Ton

Table Size: 7000*1500*600mm

Power: Low voltage rail powered

Running Speed: 0-25m/min

Warranty: 2 Years

Product Brief

Newld customer ordered 1 set coil motorized transfer trolley for workshop finished product transport. The company main business is for cold-rolled coil, pickling hot-rolled coil, galvanized coil, color-coated sheet, non-oriented silicon steel, etc..

As per our customer requirement, the rail transfer trolley plan needs to transport 3 pcs coils at a time, the coils are laid flat on the trolley, the length of one coil is about 1500mm, 20 tons. One day requires uninterrupted work. The running distance is about 150m, and the rails also need to be provided with the rail transfer trolley together. Therefore, we recommended the low voltage rail powered type transfer trolley to our customer, and without limited cable, it can freely working. Whats’ more, the v frame was installed on the cart to protect the safety of coils.

 Why Choose Us

The motorized transfer trolley is a popular material handling tools all over the world for factory transportation. We are a material handling solution designer and manufacturer with more than 20 years’ experience.

Product Information:

Model: KPD

Load: 65 Ton

Table Size: 7000*1500*600mm

Power Supply: Low Voltage Rail Power

Running Speed: 0-25m/min

Running Distance: 150m

Rail Type: P50

Color: Red

Operation: Operation Handle + Remote Control

Warranty: 2 years

Advantage: Manufacturer of rail transfer trolley; free provide design solution; free supply vulnerable part
