30 Ton Electric Rail Transfer Cart On Turntable
Product Information:
- Model: KPX-30T
- Load: 30 tons
- Size: 4000*2000*600mm
- Power Mode: Battery
- Control: Remote Control
- Motor: DC Motor
- Running Speed:0-18m/min
Product Brief
This 30 ton electric rail transfer cart with turntable is custom-designed to meet the customer's specific requirements. The system consists of two integrated components: the 30-ton rail transfer cart and a customized turntable. Featuring 360-degree rotation capability, the turntable enables precise docking of the transfer cart for heavy-load material handling in explosive atmospheres and high-temperature environments.
| Product Attributes | Technical Parameters & Configurations | Key Advantages | Safety Systems | Typical Applications |
| Basic Specs | - Rated Load: 30T | - 360° Rotating Turntable | - Explosion-proof Enclosure (Ex d IIB T4) | - Heavy Machinery Manufacturing |
| - Power: Maintenance-free Battery | - Laser Precision Positioning (±1mm) | - Dual Emergency Stop | - Steel Metallurgy Workshops | |
| - Speed: 20 m/min | - Heat-resistant Cast Steel Frame | - Audio-visual Alarm | - Automotive Assembly Lines | |
| - Charging: Portable Fast Charge | ||||
| Structural Features | - Box-girder Cast Steel Structure | - Operating Temp: -20℃~60℃ | - Laser Collision Avoidance | - Port Logistics Warehousing |
| - Flat Platform (Anti-slip Optional) | - Maintenance-free Design | - Overload Protection | - Large Component Transfer | |
| - IP54 Rating | - Noise <60dB | - Impact Absorbers | - High-temperature Work Areas | |
| Smart Control | - Wired/Wireless Dual Control | - Automatic Path Planning | - Tilt Alarm | - Smart Unmanned Factories |
| - Real-time Battery Monitoring | - Optional AGV Fleet Control | - Speed Grading Control | - Hazardous Material Handling | |
| - Self-diagnosis | - Operation Data Logging | - Emergency Obstacle Avoidance | - Precision Instrument Transport |
Product Information:
- Model: KPX-30T
- Load: 30 tons
- Size: 4000*2000*600mm
- Power Mode: Battery
- Control: Remote Control
- Motor: DC Motor
- Running Speed:0-18m/min
