Machinery Manufacturing Workshop Material Handling Rail Transfer Cart On Turntable

Product Brief

Application: The material handling rail transfer cart on turntable is an electric driven rail material handling system designed for cargoes transport in machinery manufacturing workshop from one bay to another.

Working principle: the rail transfer cart on turntable is that there are also rails installed on the turntable, when the material handling transfer cart runs on the turntable, the turntable can be rotated automatically or manually until precisely connecting with the destination rail, then the rail transfer cart runs on the vertical rail. The turntable is suitable for many occasions, such as ring rails, vertical rails, and crossing rails etc.

Product structure:

This turntable cart adopts a box girder-type frame structure to ensure high load-bearing stability;

it is equipped with a flat tabletop, suitable for loading various molds and heavy components.

Components:

Insulated wheels: 36V low-voltage power supply, safe and reliable;

Intelligent control system: wireless remote control + laser Dead Man Stop, enabling precise docking and emergency stop protection;

Safety protection: acousto-optic warning lights + safety edge + shock absorption and buffering, providing all-round protection for operation safety.

Product Information:

Model: KPD-50T/BZP-55T

Transfer Cart Load: 50 tons

Turntable Load: 55 tons

Transfer Cart Size: 2600*1900*500mm

Turntable Diameter: 3000mm

Power Supply: Low Voltage Railway
