Skeleton Frame Mini Workshop 15T Trailer For Military Plant
Product Information:
Model: BWT
Capacity: 15 ton
Qty: 11 sets
Table Size: 3000*2153*800mm
Overall Dimension: 7786*2153*800mm
Product Brief
11 sets no powered mini workshop 15t trailer was shipped to Qatar for military plant transportation. As per our customers’ requirement, the skeleton frame need to be designed to be the trailer frame so that it can towing the VAB equipment stably. And the double axle and double bar was equipped with every trailer so that they can be towed together.
Product features of skeleton trailers:
1. The use of national standard high manganese alloy steel, dense body stiffeners, strong load-bearing capacity, and a 20-year design life of the frame;
2. Adopt *** brand tires, with high elasticity, wear resistance, and more guaranteed quality;
3. Turntable slewing mechanism, stable performance, 180-degree slewing frame, small turning radius turning (turning in place);
4. The height-adjustable buffer traction mechanism, the traction heads of different tonnages can be connected only by simple adjustment; the spring reset design of the traction frame effectively reduces the stress damage of the traction frame to the frame and prolongs the service life of the body;
5. Suspended frame, compared with traditional hard connection, reduces long-term stress damage to the car body, and has a longer service life;
6. The wheel axle automatically swings and adjusts, and the convex and concave ground ensures that the board surface is level and the tire force is balanced;
Product Information:
Model: BWT
Capacity: 15 ton
Qty: 11 sets
Table Size: 3000*2153*800mm
Overall Dimension: 7786*2153*800mm
Power:Forklift Towing
Painting: Yellow
Tire: Solid tires*4
Special Requirement: Double drawbar, double linkage, foldable drawbar, shaft pin connection
